Fuji 320Kg Stylish Gearless Passenger Lift

This elegantly crafted Fuji elevator boasts a sleek design that exudes sophistication. Equipped with a robust 3.1KW motor, it effortlessly achieves a speed of 1 meter per second. With a generous load capacity of up to 320 kg, it ensures efficient transportation. Additionally, it features an array of safety measures including a door lock switch, door contact, speed governor, safety gear, and limit switches, providing peace of mind for passengers.

Type of Lift: Gearless and electric type passenger elevator

Capacity: 320kg

Motor

Power: 3.1KW

Speed: 1 meter per second

Opening

Type: Automatic 2-panel Center Opening & Side Opening available

Shaft: 700 / 800mm

Control System: Nice 3000+, AC-VF

Operation: Simplex, collective & Selective

Operating panel board

Micro push button

Alarm button

Vertical digital-type floor indicator

Interphone system way

From cabin to machine room or reception

Emergency which will come on automatically in the Car in case of power failure

Body material

Car floor: Deco rubber

Steel rope: 10mm

Landing floor door: Stainless steel etching mirror finish

Other floor door: Stainless steel hairline finish

Doorsill: Extruded Hard Aluminum

Landing board & indicators

Conformity: European safety code for elevators-En-81

Car door: Stainless Steel Golden etching mirror finish 304 grade

Car wall: Stainless Steel golden etching mirror finish 304 grade

Jamb ground floor: Only ground floor wide jamb with stainless-steel mirror finish

Handrail: Round/Flat type stainless steel handrail at the rear wall

Floor indicator

Up or down call button

Directional arrows

Power Supply

AC, 400V, 3- PH, 50HZ

AC, 220V , 1 PH, 50HZ

Guide Rail

Main guide: 10mm

Counter guide: 16mm

Cabin Call Station:

Call button with signal

Digital display

Direction arrow

Cabin Other Features

1 x Fan

1 x Intercom

Idle timer for cabin light

Emergency light with rechargeable Battery & arrival gong

All Safety

Door lock switch

Photocell-1nos

Limit switches

Door drive

Buffer spring

Speed governor

Pit stop switch

Door contact

Safety gear

Care inspection

Door re-opening evacuation device

Origin: China
